Obsolete — last-time-buy window closed
The 104878-7: A board spin is required for a functional replacement — the pinout and footprint are not shared with any current-production AMPMODU Mod II header.
104878-7 TE AMPMODU Mod II Header, 5-Pos, Obsolete
MPN104878-7
Obsolete
TE Connectivity AMP Connectors AMPMODU Mod II breakaway header, order code 104878-7, 5 positions, single row, 0.100" (2.54 mm) pitch, gold-plated mating contacts, through-hole, solder termination.
$1.7500Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.090\" (2.29mm) |
| Insulation material | Thermoplastic |
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 5 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.440\" (11.18mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to the 104878-7?
No pin-compatible successor is documented by the manufacturer. The 104878-7 uses a 0.100" pitch single-row footprint with 3 loaded positions; any replacement requires verifying the footprint and mating half against the BOM.
