50-position, 1.27 mm pitch, gold contacts
The 104895-5 is the 50-position member of TE's AMPMODU 50/50 Grid board-to-board header line, dual-row, with all positions loaded. Gold-plated mating contacts on a 0.050" (1.27 mm) pitch carry 0.5 A per contact. The header mounts surface-mount right-angle with solder termination and includes board locks and a latch holder for retention.
Board lock and latch holder
The 4-wall shrouded housing with latch holder and board locks provides mechanical retention during reflow and in service. The 0.050" (1.27 mm) row spacing matches the mating pitch, keeping the footprint symmetric for board layout.
