TE Connectivity AMP Connectors, Dynamic D-2100 series, header, 6 positions, 2.50 mm pitch, 2 rows, shrouded - 4 wall, through hole, solder termination, gold mating finish, 5 A, 250 V, UL94 V-0, black, bulk.
| Parameter | Value |
|---|---|
| Series | Dynamic D-2100 |
| Type | Tab |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 250V |
| Current rating | 5A |
| Operating temperature | -55°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.700\" (17.78mm) |
| Insulation material | Thermoplastic, Polyester, Glass Filled |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial |
| Contact shape | Rectangular |
| Rows | 2 |
| Pitch | 0.098\" (2.50mm) |
| Positions | 6 |
| Row spacing - mating | 0.148\" (3.75mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.134\" (3.40mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 1318124-1 is a TE Dynamic D-2100 series header, 6 positions loaded in 2 rows at 2.50 mm pitch, with a shrouded 4-wall design that protects the tab contacts during handling and mating.
RoHS3 compliant per the current revision.
The detent lock on the header provides audible feedback on full mate.
The header has 6 positions in 2 rows at 2.50 mm pitch, with a row spacing of 3.75 mm.
Yes, it is ROHS3 compliant per the current revision.
