0.80mm pitch, 16-position SMT receptacle for board-to-cable/wire
The 1375870-6 is a 16-position, 2-row receptacle from the AMPMODU Micro series, designed for board-to-cable/wire connections. Its defining footprint constraint is the 0.031" (0.80mm) mating pitch, which drives PCB routing density and dictates the mating header half.
SMT termination with solder retention and friction lock
The friction lock fastening type provides a positive mate with the matching header, reducing the risk of vibration-induced disconnect. The insulation height is 0.197" (5.00mm), which sets the mated stack height when paired with the corresponding header.
Sourced to order against the BOM quantity — confirm the mating half (a 0.80mm pitch, 16-position, 2-row header with friction lock) and the board footprint before committing.
Mating half and footprint fit
This receptacle mates with a 0.80mm pitch, 2-row header from the AMPMODU Micro series that has a friction lock feature. The 16-position, 2-row layout means the mating header must also be 16 positions, 2 rows.
