TE Connectivity Micro MATE-N-LOK header, 1445054-8, 8-position single-row, 3.00mm pitch, right-angle through-hole, shrouded 4-wall, locking ramp, tin-lead plating, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Micro MATE-N-LOK |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 250V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.152\" (3.85mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.118\" (3.00mm) |
| Positions | 8 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.114\" (2.90mm) |
| Contact finish - mating | Tin-Lead |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
No stock-holding claim; sourced per order.
Mates with Micro MATE-N-LOK receptacle housings — the 8-position female housing (e.g., 1445054-1 or similar) accepts the matching crimp terminals. The board lock feature provides additional SMT retention during reflow and resists shear force from the cable strain.
Yes, 1445054-8 is obsolete per TE's lifecycle status. It is available through independent distribution channels. Submit an RFQ for current availability and pricing — quantities are confirmed at quote time.
This header mates with Micro MATE-N-LOK receptacle housings, such as the 8-position female housing (common order codes include 1445054-1).
