32-position shrouded header with lever lock
The 1452368-1: Tin-plated mating contacts and a 4-wall shroud with lever lock suit it for board-to-board or cable connections where positive retention and a standard 2.54mm grid footprint are needed.
TE 1452368-1 Header, 32 Pos, 2.54mm, Shrouded
MPN1452368-1
Active
TE Connectivity AMPMODU Mod II header, order code 1452368-1, 32 positions, dual row, 0.100" (2.54mm) pitch, tin-plated mating contacts, through-hole, solder termination, shrouded - 4 wall with lever lock.
$2.7000Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Tab |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Lever Lock |
| Contact material | Copper Alloy |
| Insulation color | Gray |
| Insulation height | 0.795\" (20.20mm) |
| Insulation material | Polyethylene Terephthalate (PET), Glass Filled |
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Guide |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 32 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Tin |
Product details
Frequently asked questions
What style is 1452368-1 listed as?
Board to Board or Cable.
