TE Connectivity AMPMODU MTE header, 147324-2, 3-position single-row, 0.100" (2.54 mm) pitch, shrouded 4-wall, surface-mount right-angle, male pin, tin-lead mating finish, rated 3 A, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Board Lock, Keying Slot, Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 3 |
| Contact finish - post | Tin-Lead |
| Contact finish - mating | Tin-Lead |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The square male pin contact shape (0.025" square typical for AMPMODU MTE) mates with standard crimp-socket receptacles in the same series, giving a reliable gas-tight connection when properly terminated.
The base product number 147324 covers the AMPMODU MTE family; other position counts and plating options in the same series can consolidate SKUs if the design allows.
Sourced to order against your BOM quantity. Availability and current pricing confirmed at quote time — submit an RFQ for this exact TE AMPMODU MTE header.
