6-position AMPMODU MTE header
The 147324-5 is the 6-circuit member of TE's AMPMODU MTE single-row header line, designed for board-to-board or cable interconnect. It carries tin-lead mating contacts rated 3 A, uses a 0.100" (2.54 mm) pitch, and mounts surface-mount right-angle with solder termination.
Shrouding and retention
The 4-wall shrouding and latch holder protect the mating interface and lock the header to the receptacle, reducing the risk of disconnection under vibration. Board lock and solder retention features hold the part in place during reflow and resist shear forces from cable strain.
