TE RITS 1473571-8 — 8-Position 2.00 mm Receptacle Adapter
This is a pass-through coupling adapter, not a standard header or housing, designed to extend or reconfigure a 2.00 mm pitch interconnect without changing the mating half. Panel mount with snap-in retention means it secures into a cutout without additional hardware — a clean install for enclosure walls or bulkheads where access is limited to one side.
Mounting and Installation
Panel mount, snap-in — the adapter pushes into a rectangular panel cutout and locks with integral snaps. No screws, nuts, or brackets. The snap-in feature holds the adapter in place during mating and unmating, so the panel cutout tolerances matter — too loose and the adapter shifts under connector insertion force.
