147382-1 TE Connectivity AMPMODU 50/50 Grid Header 10-Pin

MPN147382-1
Active

TE Connectivity AMPMODU 50/50 Grid header, 147382-1, board-to-board, 10 positions, 2 rows, 0.050" (1.27mm) pitch, 0.5A per contact, gold mating finish, surface mount, shrouded - 4 wall, board lock, pick and place, tape and reel.

$4.2703Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 147382-1 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

147382-1 key specifications
ParameterValue
SeriesAMPMODU 50/50 Grid
TypeMale Pin
MountingSurface Mount
Connector typeHeader
Fastening typePush-Pull
Current rating0.5A per Contact
Operating temperature-65°C ~ 105°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.298\" (7.57mm)
Insulation materialLiquid Crystal Polymer (LCP)
Mated stacking heights8.13mm

All specifications

147382-1 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTape & Reel (TR)
FeaturesBoard Lock, Pick and Place
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Medical, Military, Telecommunications
Contact shapeCircular
Rows2
Pitch0.050\" (1.27mm)
Positions10
Row spacing - mating0.050\" (1.27mm)
Contact finish - postTin-Lead
Contact finish - matingGold
Contact length - mating0.120\" (3.05mm)
Contact finish thickness - post150.0µin (3.81µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

0.050" Pitch Board-to-Board Header with 8.13mm Stack Height

Surface Mount with Pick-and-Place Features

Termination is solder, surface mount, with a pick-and-place feature for automated assembly. Packaged in Tape and Reel (TR), compatible with standard SMT pick-and-place feeders.

Sourced through independent distribution channels.

Application Range and Compliance

The mating finish is gold (30µinch / 0.76µm), providing low contact resistance and corrosion resistance for repeated mate/unmate cycles.

Frequently asked questions

What is the pitch of 147382-1?

The pitch is 0.050" (1.27mm) on both the mating pitch and the row spacing — a square grid.

What is the mating connector for 147382-1?

147382-1 is a male pin header. It mates with a female receptacle from the same AMPMODU 50/50 Grid series with a 0.050" (1.27mm) pitch and 10 positions. The specific mating part number depends on the termination style (SMT, through-hole, IDC) and orientation required.

Where can I buy 147382-1?

147382-1 is available through independent distribution.
