TE Connectivity AMP Connectors 173926-1
MPN173926-1
Active
CONN HEADER VERT 4POS 6.35MM
$15.47Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesUniversal MATE-N-LOK
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Universal MATE-N-LOK |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 500VAC |
| Current rating | 15A |
| Operating temperature | -25°C ~ 85°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.624\" (15.85mm) |
| Insulation material | Thermoplastic, Glass Filled |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Shrouded - 4 Wall |
| Termination | Press-Fit, Solder |
| Applications | General Purpose |
| Rows | 1 |
| Pitch | 0.250\" (6.35mm) |
| Positions | 4 |
| Contact finish - post | Tin |
| Contact length - post | 0.189\" (4.80mm) |
| Overall contact length | 0.764\" (19.40mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 20.0µin (0.51µm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
