TE Connectivity AMP Connectors 1761608-6 — Pin Headers

1761608-6 TE Connectivity AMP-Latch Header 16 Pos 2.54mm

MPN1761608-6
Active

TE Connectivity AMP-Latch series, 1761608-6, shrouded 4-wall header, 16 circuits, 2 rows, 0.100" (2.54 mm) pitch, through-hole solder termination, male pin contacts with 30 µinch gold mating finish, rated 1 A per contact at 250 VAC.

$7.3600Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1761608-6 datasheet (PDF)
RoHSRoHS Compliant
SeriesAMP-Latch
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1761608-6 key specifications
ParameterValue
SeriesAMP-Latch
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLatch Lock/Eject Hooks, Short
Voltage rating250VAC
Current rating1A per Contact
Operating temperature-65°C~105°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.404\" (10.26mm)
Insulation materialPolybutylene Terephthalate (PBT)

All specifications

1761608-6 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTube
FeaturesKeying Slot
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions16
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.102\" (2.60mm)
Contact finish - matingGold or Gold-Palladium
Contact length - mating0.237\" (6.02mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

16 Circuits, 0.100" Pitch — AMP-Latch Header Identity

1 A Signal Duty vs 5 A Power — Peer Comparison

Compared to the 1318699-3, a 12-position, 4-row header at 0.165" pitch rated 5 A per contact, the 1761608-6 is a signal-density part. The 30 µinch gold mating finish on this header is ten times the 3 µinch gold on the 1318699-3 — a meaningful difference if the connector sees frequent unmating in a corrosive environment. The 1318699-3 uses circular pins; this one uses square pins, which give a slightly larger contact wipe area.

RoHS compliant per the listing.

Frequently asked questions

What is the mating connector for 1761608-6?

This is a board-to-cable/wire header. The latch lock/eject hooks engage with the receptacle's locking ears for positive retention.

What is the pinout of 1761608-6?

The header has 16 positions, all loaded, arranged in two rows. The pinout follows the standard AMP-Latch grid pattern — consult the product drawing for the exact row and column numbering relative to the keying slot.
