9-Position Shrouded Header for Wire-to-Board Harnesses
The 1775469-9 is a 9-position, single-row, surface-mount right-angle header from the TE High Performance Interconnect (HPI) series. Its 2.00mm pitch and full 4-wall shrouding make it a direct fit for a wire-to-board harness that needs blind-mate alignment and vibration resistance. Solder retention features help hold the part during reflow.
RoHS3 compliant per.
Mating and Termination Fit
This header mates with a 2.00mm-pitch crimp receptacle housing (TE HPI series). The 9-position, single-row layout accepts the corresponding female connector with 4-wall shroud clearance. Termination is solder — the SMT tails reflow onto the board pads.
