TE Connectivity AMP Connectors 2-103673-4 — Pin Headers, Sockets & Housings

2-103673-4 TE AMPMODU MTE Header 25 Pos 2.54mm Right Angle

MPN2-103673-4
Active

TE Connectivity AMPMODU MTE, 25-position single-row shrouded header, 0.100" (2.54mm) pitch, right-angle through-hole, gold-plated mating pins, board lock and latch holder, rated 3 A per contact.

$4.5868Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 2-103673-4 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

2-103673-4 key specifications
ParameterValue
SeriesAMPMODU MTE
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typeLatch Holder
Current rating3A
Operating temperature-65°C ~ 105°C
Contact materialBrass
Insulation colorBlack
Insulation height0.200\" (5.08mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

2-103673-4 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTube
FeaturesBoard Lock, Keying Slot
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions25
Contact finish - postTin
Contact length - post0.130\" (3.30mm)
Contact finish - matingGold
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Pitch and Position Count — BOM Fit Check

The 2-103673-4: All 25 positions are loaded, so no empty pin locations to account for. Compared to the 10-position sibling in the same AMPMODU MTE series, this 25-position version occupies 2.5× the board edge length — a meaningful difference for enclosure width budgeting.

The UL94 V-0 thermoplastic housing limits continuous current before the temperature rise exceeds the material rating.

Mating and Latching

Shrouded with four walls and a latch holder — mates with AMPMODU MTE receptacles that carry the corresponding latch.

Frequently asked questions

Where to buy 2-103673-4 with stock?

Sourcing buyers need immediate availability to avoid production delays.

What is the price of 2-103673-4?

Price is a primary factor for procurement decisions and budget planning.

What are the dimensions of 2-103673-4?

Design engineers need precise dimensions for PCB layout and mechanical fit.

Is 2-103673-4 RoHS compliant?

Compliance is mandatory for many industries and affects regulatory acceptance.

Can 2-103673-4 replace 2-103673-3?

Techs and buyers need to verify interchangeability for maintenance or BOM changes.

What is the lifecycle status of 2-103673-4?

Brokers and long-term buyers need to know if the part is active or nearing obsolescence.
