TE Connectivity VAL-U-LOK 2-1586038-2, 22-circuit dual-row board-to-wire header, 4.20 mm pitch, 9 A per circuit at 600 VAC, tin-plated brass contacts, 4-wall shroud with locking ramp, through-hole solder termination, -40°C to 105°C operating range, UL94 V-0 polyamide insulation.
| Parameter | Value |
|---|---|
| Series | VAL-U-LOK |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 600VAC |
| Current rating | 9A |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass Alloy |
| Insulation color | Natural |
| Insulation height | 0.504\" (12.80mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial, Lighting |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.165\" (4.20mm) |
| Positions | 22 |
| Row spacing - mating | 0.165\" (4.20mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.138\" (3.50mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 80.0µin (2.03µm) |
| Contact finish thickness - mating | 80.0µin (2.03µm) |
The 4-wall shroud and locking ramp fastening mean it mates securely with the matching VAL-U-LOK receptacle housing — the ramp locks audibly and resists vibration better than a friction-only header.
Applications listed include General Purpose, Industrial, and Lighting — the locking ramp and shrouded walls make it suitable for equipment that sees occasional vibration or cable strain.
No. The lifecycle status is Active. If you are looking for a functional alternative, the peer MPN 4-1775099-7 is a similar VAL-U-LOK header but verify the position count and pitch match your application.
Sourced to order against the BOM quantity. Availability and pricing confirmed at quote time.
