TE Connectivity VAL-U-LOK 2-1586041-2, dual-row 22-position shrouded header, 4.20 mm pitch, right-angle through-hole, 9 A per circuit at 600 VAC, tin-plated brass contacts, -40 to 105 °C operating temperature, locking ramp fastening.
| Parameter | Value |
|---|---|
| Series | VAL-U-LOK |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 600VAC |
| Current rating | 9A |
| Operating temperature | -40°C~105°C |
| Contact material | Brass Alloy |
| Insulation color | Natural |
| Insulation height | 0.402\" (10.20mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-2 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial, Lighting |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.165\" (4.20mm) |
| Positions | 22 |
| Row spacing - mating | 0.165\" (4.20mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.142\" (3.60mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 80.0µin (2.03µm) |
| Contact finish thickness - mating | 80.0µin (2.03µm) |
The 2-1586041-2 is a dual-row, 22-position shrouded header from the VAL-U-LOK series by TE Connectivity AMP Connectors. The 4.20 mm pitch and 9 A per circuit rating at 600 VAC make it suited for power distribution in industrial controls, lighting fixtures, and general-purpose equipment where the board needs to deliver moderate current to a remote harness.
Yes, it is ROHS3 compliant, meaning it meets the current EU RoHS directive including the exemption list.
