TE Connectivity AMP Connectors AMPMODU receptacle, order code 2-1734516-0, 20 positions, dual row, 2.00 mm pitch, 1 A, 250 VAC, gold-plated mating contacts, surface-mount, solder termination.
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Female Socket |
| Mounting | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Voltage rating | 250VAC |
| Current rating | 1A |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.175\" (4.45mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Board Guide, Pick and Place |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 20 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 2-1734516-0 is the 20-position dual-row member of TE's AMPMODU board-to-board receptacle line, surface-mount with push-pull fastening.
The 0.175" insulation height and board guide features aid alignment during SMT placement.
The housing is rated UL94 V-0. Full RoHS/REACH documentation is available through the TE compliance portal.
