14-position right-angle header for AMP-Latch ribbon cable assemblies
Mating half and locking fit
This header mates with standard AMP-Latch IDC sockets (e.g., 1-111626-4 or similar 14-position, 0.100" pitch receptacles) and accepts 0.100" pitch ribbon cable. The short eject hooks provide a positive latch that engages the socket's locking ears — the latch is shorter than full-length ejectors, so it stays within the header body outline for tighter board layouts. The 0.237" (6.02mm) mating pin length ensures full contact wipe inside the socket's tuning-fork contacts.
