TE Connectivity AMP Connectors 2-338069-4 — Female Socket Headers

2-338069-4 TE Connectivity Micro-MaTch 24-Pin Receptacle

MPN2-338069-4
Active

TE Connectivity AMP Connectors Micro-MaTch series, receptacle, 24 positions, 0.100" (2.54mm) pitch, dual row, tin-plated forked contacts, SMD termination, friction lock, red PA46 housing, -40°C to 105°C, ROHS3.

$5.2400Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesMicro-MaTch
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

2-338069-4 key specifications
ParameterValue
SeriesMicro-MaTch
TypeForked
MountingSurface Mount
Connector typeReceptacle
Fastening typeFriction Lock
Voltage rating100VDC
Operating temperature-40°C ~ 105°C
Contact materialPhosphor Bronze
Insulation colorRed
Insulation height0.209\" (5.30mm)
Insulation materialPolyamide (PA46), Nylon 4/6, Glass Filled
Material flammability ratingUL94 V-0

All specifications

2-338069-4 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTape & Reel (TR) Cut Tape (CT)
TerminationSolder
ApplicationsAutomotive, General Purpose
Rows2
Pitch0.100\" (2.54mm)
Positions24
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact finish - matingTin

Product details

What this 24-pin Micro-MaTch receptacle does

The 2-338069-4: This is a 24-position, dual-row receptacle from TE's Micro-MaTch series, pitched at 0.100" (2.54mm) — the standard spacing for breadboard and prototyping layouts, but also found in production automotive and general-purpose board-to-board or cable assemblies.

Compared to the 12-position sibling 1-2823056-2, this part doubles the circuit count while keeping the same pitch, row spacing, and tin plating — a direct BOM swap if the board layout has the extra footprint length. The 5.30 mm insulation height is typical for a shrouded SMD receptacle; confirm the mating header's stack height clears the enclosure lid or adjacent components.

CT works for prototypes or low-volume builds.

Frequently asked questions

Is 2-338069-4 RoHS compliant?

Yes, it is ROHS3 compliant.

Does 2-338069-4 have a locking feature?

Yes, it uses a friction lock — not a positive latch, but enough to resist vibration in automotive and general-purpose applications.

What is the closest functional second-source for 2-338069-4?

The peer 1-2823056-2 is a 12-position, black-housed variant with the same pitch, row spacing, tin plating, and SMD termination — a direct drop-in for half the circuit count if the board footprint allows.
