TE Connectivity Diplomate DL DIP header, 28 positions (2 x 14), 0.100" (2.54 mm) pitch, 0.600" (15.24 mm) row spacing, through-hole solder termination, tin-plated phosphor bronze contacts, open-frame thermoplastic housing, UL94 V-0.
| Parameter | Value |
|---|---|
| Type | DIP, 0.6\" (15.24mm) Row Spacing |
| Series | Diplomate DL |
| Mounting | Through Hole |
| Operating temperature | -55°C ~ 105°C |
| Housing material | Thermoplastic |
| Contact material - post | Phosphor Bronze |
| Contact material - mating | Phosphor Bronze |
| Material flammability rating | UL94 V-0 |
| Package | Tube |
| Features | Open Frame |
| Termination | Solder |
| Pitch - post | 0.100\" (2.54mm) |
| Pitch | 0.100\" (2.54mm) |
| Contact resistance | 30mOhm |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Termination post length | 0.128\" (3.24mm) |
| Number of positions or pins | 28 (2 x 14) |
The 2-382467-3: The open-frame design gives you access to the board for trace routing between the rows. Mating contacts are tin-plated phosphor bronze; the post finish is also tin.
Available through independent surplus and aftermarket distribution.
The tin-to-tin contact interface is compatible with both tin and gold socket contacts, though gold-on-tin mating is preferred for corrosive environments.
Yes, 2-382467-3 is obsolete. TE Connectivity does not list a direct pin-compatible replacement. If you need a 28-position DIP header with 0.600" row spacing, you'll need to evaluate alternatives from other manufacturers — the footprint is standard, but confirm the post length and contact plating match your application.
Through independent distribution channels. No stock is held on the shelf.
