TE Connectivity AMP Connectors Diplomate DL header, order code 2-382568-0, 20 positions, dual row, 0.100" (2.54mm) pitch, tin-plated mating contacts, through-hole, solder termination, DIP 0.3" (7.62mm) row spacing.
TE 2-382568-0 Diplomate DL 20-Pin DIP Header, Obsolete
MPN2-382568-0
Obsolete
TE Connectivity AMP Connectors Diplomate DL header, order code 2-382568-0, 20 positions, dual row, 0.100" (2.54mm) pitch, tin-plated mating contacts, through-hole, solder termination, DIP 0.3" (7.62mm) row spacing.
$0.4400Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Type | DIP, 0.3\" (7.62mm) Row Spacing |
| Series | Diplomate DL |
| Mounting | Through Hole |
| Operating temperature | -55°C ~ 105°C |
| Housing material | Thermoplastic, Glass Filled |
| Contact material - post | Phosphor Bronze |
| Contact material - mating | Phosphor Bronze |
| Material flammability rating | UL94 V-0 |
| Package | Tube |
| Features | Closed Frame |
| Termination | Solder |
| Pitch - post | 0.100\" (2.54mm) |
| Pitch | 0.100\" (2.54mm) |
| Contact resistance | 30mOhm |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Termination post length | 0.128\" (3.24mm) |
| Number of positions or pins | 20 (2 x 10) |
Product details
Frequently asked questions
Where can I buy the 2-382568-0 and get a price?
The 2-382568-0 is available through independent surplus channels; quantities and pricing are confirmed at RFQ. No last-time-buy stock is held on site.
What is the closest pin-compatible alternative to the 2-382568-0?
No pin-compatible alternative is documented in the Diplomate DL series. Any functional replacement would require a different pinout and board layout.
