TE Connectivity AMP Connectors 2-826631-4 — Pin Headers, Sockets & Housings

TE AMPMODU Mod II 2-826631-4 Header, 24 Pos, 2.54mm

MPN2-826631-4
Active

TE Connectivity AMP Connectors AMPMODU Mod II header, breakaway, order code 2-826631-4, 24 positions, single row, 2.54 mm pitch, 5 A, gold-plated mating contacts, through-hole right-angle, solder termination.

$1.6859Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 2-826631-4 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

2-826631-4 key specifications
ParameterValue
SeriesAMPMODU Mod II
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader, Breakaway
Fastening typePush-Pull
Current rating5A
Operating temperature-65°C~105°C
Contact materialBrass
Insulation colorGreen
Insulation height0.120\" (3.05mm)
Insulation materialPolybutylene Terephthalate (PBT)
Material flammability ratingUL94 V-0

All specifications

2-826631-4 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions24
Contact finish - postTin
Contact length - post0.126\" (3.20mm)
Contact finish - matingGold
Contact length - mating0.264\" (6.70mm)
Contact finish thickness - post118.1µin (3.00µm)
Contact finish thickness - mating3.90µin (0.099µm)

Product details

24-position breakaway, gold mating side

The 2-826631-4 is the 24-position member of the TE AMPMODU Mod II breakaway header line, unshrouded with a push-pull fastening system. Gold plating on the mating contact (3.90 µin) handles repeated mate cycles; the tin-plated post (118.1 µin) solders into the board. Rated 5 A per contact with a UL94 V-0 PBT housing.

Single-row right-angle layout

Single-row, through-hole right-angle mounting — the 0.126" post length suits standard PCB thicknesses. The unshrouded design leaves the pins exposed for easy probing or hand-wiring after assembly.

Frequently asked questions

What is the listed style and series for 2-826631-4?

The style is Board to Board or Cable, and the series is AMPMODU Mod II.
