TE Connectivity AMP Connectors AMPMODU Mod II header, order code 2-86479-7, 46 positions, dual row, 0.100" (2.54mm) pitch, 3 A, gold mating contacts, through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.238\" (6.05mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tray |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 46 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Gold |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | Flash |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 2-86479-7 is a 46-position, dual-row header from TE Connectivity's AMPMODU Mod II series, unshrouded, with a push-pull fastening system.
The 2-86479-7 is listed as Obsolete by the manufacturer. No official successor or pin-compatible alternative is recorded for this AMPMODU Mod II header.
The 2-86479-7 is listed with a Style of Board to Board or Cable, per the AMPMODU Mod II header specification.
