44-position unshrouded header, AMPMODU Mod II
The 2-87215-2: Mating contacts are gold-plated (30.0µin) on phosphor bronze, rated 3 A per contact.
Obsolete — no direct replacement
The 2-87215-2 is listed as Obsolete by TE Connectivity.
TE 2-87215-2 Header, 44 Pos, 2.54mm, Obsolete
MPN2-87215-2
Obsolete
TE Connectivity AMPMODU Mod II header, order code 2-87215-2, 44 positions, dual row, 0.100" (2.54mm) pitch, 3 A, gold-plated mating contacts, through hole, solder termination, black thermoplastic housing, UL94 V-0.
$8.5100Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.090\" (2.29mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Circular |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 44 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Gold |
| Contact length - post | 0.125\" (3.18mm) |
| Overall contact length | 0.533\" (13.55mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | Flash |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the 2-87215-2's style and series?
The style is Board to Board or Cable, and the series is AMPMODU Mod II.
