TE Connectivity AMPMODU Mod II header, order code 2-87224-5, 25 positions, single row, 0.100" (2.54mm) pitch, 3A, gold-plated mating contacts, through-hole, solder termination.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.090\" (2.29mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 25 |
| Contact finish - post | Gold |
| Contact length - post | 0.125\" (3.18mm) |
| Overall contact length | 0.533\" (13.55mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | Flash |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 2-87224-5 is a 25-position single-row header from TE's AMPMODU Mod II series, unshrouded with push-pull fastening, rated 3A per contact. Gold-plated mating contacts (15.0µin) and a UL94 V-0 thermoplastic housing suit it for signal-level board-to-board or cable connections.
The 2-87224-5 is listed as Obsolete by TE Connectivity AMP Connectors. Expect lot-specific supply and no factory lead time.
The 2-87224-5 is available through independent surplus channels. Request a quote with quantity to confirm availability and pricing.
