TE Connectivity AMPMODU Mod IV receptacle housing, 2-87456-2, 26 positions, 2 rows, 0.100" (2.54mm) pitch, 0.100" (2.54mm) row spacing, free-hanging (in-line), crimp termination, black nylon housing, -65°C to 105°C.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod IV |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Operating temperature | -65°C ~ 105°C |
| Color | Black |
| Insulation material | Polyamide (PA), Nylon, Glass Filled |
| Note | Contacts Not Included |
| Pitch | 0.100\" (2.54mm) |
| Package | Bulk |
| Row spacing | 0.100\" (2.54mm) |
| Rows | 2 |
| Contact termination | Crimp |
| Positions | 26 |
Both the pitch between adjacent contacts in a row and the row spacing are 0.100" (2.54mm). This gives a symmetrical grid that aligns with standard 0.100" header pin fields, making board layout and harness routing straightforward.
This housing accepts AMPMODU Mod IV female socket crimp contacts. The dual-row layout requires 26 individual contacts for a full populate.
The 2-87456-2 accepts AMPMODU Mod IV female socket crimp contacts. Contacts are not included with the housing — order them separately.
