TE Connectivity AMP Connectors 2-963207-1 — Connector Housings

TE 2-963207-1 Junior Power Timer Receptacle, 4 Pos, Sealed

MPN2-963207-1
Active

TE Connectivity Junior Power Timer receptacle housing, 2-963207-1, 4 positions, 5.00 mm pitch, 1 row, gray PBT, sealed, free-hanging, crimp termination, contacts not included.

$4.0000Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesJunior Power Timer
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

2-963207-1 specifications
ParameterValue
SeriesJunior Power Timer
TypeFemale Socket
MountingFree Hanging (In-Line)
Connector typeReceptacle
ColorGray
Insulation materialPolybutylene Terephthalate (PBT), Glass Filled
NoteContacts Not Included
Pitch0.197\" (5.00mm)
PackageBulk
FeaturesSealed
Rows1
Contact terminationCrimp
Positions4

Product details

Receptacle Housing for Sealed Harness Applications

The gray PBT, glass-filled housing is rated for free-hanging (in-line) mounting, and the sealed construction keeps moisture and contaminants out of the connection — critical for underhood or exposed harness runs.

Sealed Housing — No Terminals Included

The locking ramp on the mating plug provides audible and tactile confirmation of full engagement, and the sealed interface means no secondary boot or heat shrink is required at the joint.

This receptacle mates with the Junior Power Timer plug housing (male tab contacts), also from the same series. The crimp terminals for this housing are the standard Junior Power Timer female sockets — verify the wire gauge range and plating (tin vs. gold) against your application's current and cycle-life requirements. The locking ramp on the plug side engages with the ramp on this receptacle to prevent accidental unmating under vibration.

Frequently asked questions

Where can I buy 2-963207-1 and get a price?

Submit a request for your target quantity to receive current pricing and lead time — availability is confirmed at quote time.

Is 2-963207-1 a sealed connector?

Yes, the 2-963207-1 is a sealed receptacle housing, listed with the Sealed feature. It is designed for environments where moisture and dust ingress must be prevented — typical for automotive underhood or outdoor industrial harnesses.

What contacts are compatible with 2-963207-1?

The 2-963207-1 accepts female socket crimp terminals from the Junior Power Timer series. Contacts are not included with the housing and must be ordered separately. Select the terminal based on your wire gauge and plating needs (tin for standard duty, gold for higher cycle life or corrosive environments).
