Two-position SMT header with a locking ramp
The 2029030-2 is a 2-position, single-row header from the Micro MATE-N-LOK series, pitched at 3.00 mm. The housing is fully shrouded on all four walls, so the male pins are protected during handling and the mating receptacle aligns without stubbing. A locking ramp on the top engages the matching receptacle latch — no secondary clip needed for vibration resistance.
Pitch, plating, and temperature range
The 3.00 mm pitch is wider than the 2.50 mm of the 1-1871673-2 peer, which gives more room for trace routing between pads on the board. The current rating is listed as varying by wire gauge — on a 2-position header the limiting factor is the attached wire, not the contact itself.
