TE Connectivity AMP Metrimate series, 207119-2, shrouded 4-wall header, 4 positions loaded, 2 rows, 4.98 mm pitch, through-hole solder termination, tin-plated male pins, rated 7.5 A at 600 V, UL94 V-0, -55°C to 130°C.
| Parameter | Value |
|---|---|
| Series | Metrimate |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Lock |
| Voltage rating | 600V |
| Current rating | 7.5A |
| Operating temperature | -55°C~130°C |
| Contact material | Brass |
| Insulation color | Black, Red |
| Insulation height | 0.464\" (11.79mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial |
| Contact shape | Circular |
| Rows | 2 |
| Pitch | 0.196\" (4.98mm) |
| Positions | 4 |
| Row spacing - mating | 0.196\" (4.98mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.181\" (4.60mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
The 207119-2: The tin-plated brass contacts are rated 7.5 A per circuit at 600 V, with a full 150.0 µin tin thickness on both the mating face and the solder post — adequate for moderate-cycle applications where gold is not required.
The 4-wall shroud prevents misalignment and protects pins during blind mating. Termination is through-hole solder to the PCB. The 0.181" post length suits standard board thicknesses; the 4.60 mm post accommodates wave-solder or hand-solder assembly.
