36-Position, 4-Row Metrimate Header for Board-to-Cable Wiring
Rated at 7.5 A per circuit and 600 V, with a tin-lead mating finish at 150.0µin (3.81µm) thickness, this header handles moderate power loads in environments where repeated mating is infrequent — the tin-lead interface is cost-effective for field-installed equipment that stays mated for extended periods.
The part ships in tray packaging.
Mating Half and Build-to-Print BOM
This is a female socket header — it mates with a male pin header from the Metrimate series (typically a plug housing with crimp contacts). For a complete build-to-print assembly, you need the header, the mating plug housing, and the appropriate crimp terminals — all sold separately. The mounting flange adds a screw-down option for extra panel retention.
Peer Comparison: 207534-8 vs. 1-2823056-2
The 207534-8 carries 36 positions at 5.00mm pitch and 600 V, making it suitable for higher-power, higher-density board-to-cable interconnects where the 1-2823056-2 would be undersized. No pin-to-pin compatibility exists; these are separate product families.
