The 2137614-2: This is a 32-position, dual-row, vertical through-hole header from the AMPMODU Mod II series, with a 0.100" (2.54mm) pitch on both rows and between rows.
With 32 positions loaded all, this header matches a standard 0.100" x 0.100" grid. The 0.118" (3.00mm) post length suits typical 1.6mm PCBs; the 0.268" (6.80mm) mating pin length provides a solid wipe inside the receptacle. The overall contact length of 0.520" (13.21mm) and insulation height of 0.795" (20.20mm) define the z-height budget when mated — confirm your board-to-board stack-up or cable clearance.
Active Production and Sourcing Status
No stock-holding claim; each quote reflects the latest manufacturer availability.
