TE Connectivity AMP Connectors, Micro-MaTch series, 4-position receptacle, 2.54mm pitch, through-hole right-angle, tin-on-tin contacts, push-pull fastening, active production.
| Parameter | Value |
|---|---|
| Series | Micro-MaTch |
| Type | Forked |
| Mounting | Through Hole, Right Angle |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Voltage rating | 100VDC |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Red |
| Insulation height | 0.228\" (5.80mm) |
| Insulation material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Termination | Kinked Pin, Solder |
| Applications | Automotive, General Purpose |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 4 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.122\" (3.10mm) |
| Contact finish - mating | Tin |
Tin plating is cost-effective for low-cycle applications (typically under 25 mating cycles) but can frett in high-vibration or frequent-remate scenarios. If your assembly sees repeated disconnect-reconnect cycles, the gold-plated sibling 1376775-2 (8.00µin gold on mating surface) is worth a look.
The matching male half is typically a TE Micro-MaTch header with the same pitch and row spacing; confirm the pin count and orientation against your assembly drawing before committing.
Yes, it is ROHS3 compliant.
