2.54mm pitch, 4-position shrouded header
Rated 1.5A per contact at 230V, this header suits signal-level interconnects in general-purpose board-to-board or cable applications.
Press-fit termination and latch lock
Termination is press-fit with a solder option — the press-fit tail eliminates the need for a wave solder step, reducing thermal stress on the PCB and assembly time. The through-hole mounting and 0.122" (3.10mm) post length are compatible with standard PCB thicknesses. Insulation height of 0.142" (3.60mm) leaves clearance for routing under the header.
