5.00 mm Pitch, 3 Loaded Positions — What This Means for Your Board
The 2232511-5: With 5 positions in the housing but only 3 contacts loaded, this header is designed for applications where the full cavity count isn't needed — common in appliance control boards and industrial I/O modules where one or two circuits carry the signal and the rest are unused or reserved.
Glow Wire Compliance and Latch Holder for Appliance and Industrial Use
Glow wire compliant per IEC 60335-1 — this is a mandatory safety requirement for connectors in household appliances and certain industrial equipment where a glowing hot wire must not ignite the housing. The UL94 V-0 nylon housing supports this rating.
Voltage, Temperature, and Material Ratings for Harsh Environments
Rated 250 VAC, this header can carry line-voltage signals and low-power loads in appliance and industrial control circuits. The rectangular tab contact shape mates with standard 5.00 mm pitch crimp receptacles.
Packaged in bulk, this header is ready for automated or hand insertion. The base product number 2232511 covers the series; the -5 suffix indicates the specific position count and loading configuration.
