TE Connectivity AMP Connectors AMPMODU Mod II header, 280385-2, 16 positions, 0.100" (2.54mm) pitch, dual-row, shrouded-3 wall, through-hole solder, gold-plated mating pins, detent lock, 3 A per contact.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 40V |
| Current rating | 3A |
| Operating temperature | -40°C~80°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.496\" (12.60mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Shrouded - 3 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 16 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.138\" (3.50mm) |
| Overall contact length | 0.563\" (14.30mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.260\" (6.60mm) |
| Contact finish thickness - post | 98.4µin (2.50µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The detent lock provides audible feedback on mate and resists vibration-induced separation once engaged.
The 280385-2 offers 16 positions vs 4, a vertical orientation, 3-wall shroud, and gold mating finish — a different board footprint and position count for higher-density, vertical-mate applications.
The pitch is 0.100" (2.54mm) and it has 16 positions in a dual-row layout.
