TE Connectivity AMPMODU Mod II, 280581-2, Board to Board, Receptacle, 15 Positions, 0.100" (2.54mm) Pitch, Through Hole, Right Angle, Gold Mating Finish, Friction Lock
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Female Socket |
| Mounting | Through Hole, Right Angle |
| Connector type | Receptacle |
| Fastening type | Friction Lock |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.157\" (4.00mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 15 |
| Contact finish - post | Gold |
| Contact length - post | 0.138\" (3.50mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | Flash |
| Contact finish thickness - mating | 16.0µin (0.41µm) |
Both the mating and post contact finishes are gold, with the mating surface plated to 16.0µin (0.41µm). That thickness supports repeated mating cycles — typically several hundred — without exposing the base phosphor bronze to oxidation, making this receptacle a reliable choice for field-serviceable connections where the board may be disconnected and reconnected over the product life.
The 280581-2 is a 15-position single-row receptacle. All positions are loaded. The pinout is a linear 1×15 array on 0.100" (2.54mm) pitch.
The friction lock engages with a corresponding ramp on the header housing. Confirm the header's position count and orientation (straight or right-angle) to match your board layout.
