TE Connectivity AMPMODU Mod I header, order code 280616-1, 4 positions, single row, 0.156" (3.96mm) pitch, tin-plated mating contacts, through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod I |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Detent Lock |
| Contact material | Brass |
| Insulation color | Green |
| Insulation height | 0.346\" (8.80mm) |
| Insulation material | Polycarbonate, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Contact shape | Rectangular |
| Rows | 1 |
| Pitch | 0.156\" (3.96mm) |
| Positions | 4 |
| Contact finish - post | Tin |
| Contact length - post | 0.126\" (3.20mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.394\" (10.00mm) |
The 280616-1 is the 4-circuit member of TE Connectivity's AMPMODU Mod I header line, a single-row shrouded header on 0.156" (3.96mm) pitch. Mating contacts are tin-plated brass; the header mounts through-hole right-angle with solder termination and includes a detent lock for secure mating.
