TE Connectivity AMPMODU Mod I header, 280617-1, 6 positions, 0.156" (3.96mm) pitch, through-hole right-angle, shrouded-2 wall, detent lock, tin-plated male pins, UL94 V-0 green polycarbonate housing.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod I |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Detent Lock |
| Contact material | Brass |
| Insulation color | Green |
| Insulation height | 0.346\" (8.80mm) |
| Insulation material | Polycarbonate, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Contact shape | Rectangular |
| Rows | 1 |
| Pitch | 0.156\" (3.96mm) |
| Positions | 6 |
| Contact finish - post | Tin |
| Contact length - post | 0.126\" (3.20mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.394\" (10.00mm) |
The 280617-1 is a 6-position, single-row, shrouded header from the AMPMODU Mod I series, with a 0.156" (3.96mm) pitch — wider than the common 2.54mm, so the footprint and mating connector are specific to this spacing.
Mating contact finish is tin, which suits moderate mating-cycle applications in dry indoor environments.
The 280617-1 mates with a 0.156" (3.96mm) pitch, 6-position, single-row receptacle — typically an AMPMODU Mod I or compatible crimp housing. Confirm the contact and housing part numbers against your wire gauge and application before ordering.
Yes, the 280617-1 is listed as ROHS3 compliant.
