TE Connectivity AMPMODU Mod II, 12-position single-row receptacle, 0.100" (2.54mm) pitch, through-hole right-angle solder termination, tin-plated phosphor bronze contacts, friction lock, UL94 V-0 black polyester housing.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Female Socket |
| Mounting | Through Hole, Right Angle |
| Connector type | Receptacle |
| Fastening type | Friction Lock |
| Operating temperature | -65°C~105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.157\" (4.00mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Contact finish - post | Tin |
| Contact length - post | 0.138\" (3.50mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 30.0µin (0.76µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 281336-1: The 12 positions are fully loaded — no depopulation to track on the BOM. The friction lock provides a positive retention force against vibration — the mating header clicks into place and stays there without a secondary latch mechanism, simplifying field assembly.
The post finish is also tin, so the solder joint is compatible with standard lead-free wave or hand-solder processes.
