TE Connectivity HE13/HE14 series, 281838-3, 3-position 1-row receptacle housing, 0.100" (2.54mm) pitch, free-hanging, crimp termination, PBT glass-filled, black, -55°C to 125°C.
| Parameter | Value |
|---|---|
| Series | HE13/HE14 |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Operating temperature | -55°C ~ 125°C |
| Color | Black |
| Insulation material | Polybutylene Terephthalate (PBT), Glass Filled |
| Note | Contacts Not Included |
| Pitch | 0.100\" (2.54mm) |
| Package | Bulk |
| Rows | 1 |
| Contact termination | Crimp |
| Positions | 3 |
Contacts are not included. This is an empty shell.
The free-hanging design lets it plug into a board-mounted header or into a mating plug housing in a harness-to-harness configuration. Termination is crimp-only.
For a multi-year production program, this housing can be specified without obsolescence risk — the HE13/HE14 series is a mature, widely-used TE Connectivity platform that remains in active manufacture.
No. The 281838-3 is a housing only — contacts are not included. You must order the matching HE13/HE14 female crimp socket terminals separately.
Submit your target quantity and lead time for a current price and availability confirmation.
