TE Connectivity AMP Connectors HE13/HE14 series, 281839-6, receptacle housing, 12 circuits, 0.100" (2.54mm) pitch, dual-row, free hanging (in-line), detent lock, black PBT glass-filled body, -55°C to 125°C, contacts not included.
| Parameter | Value |
|---|---|
| Series | HE13/HE14 |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Fastening type | Detent Lock |
| Operating temperature | -55°C ~ 125°C |
| Color | Black |
| Insulation material | Polybutylene Terephthalate (PBT), Glass Filled |
| Note | Contacts Not Included |
| Pitch | 0.100\" (2.54mm) |
| Package | Bulk |
| Row spacing | 0.100\" (2.54mm) |
| Rows | 2 |
| Contact termination | Crimp |
| Positions | 12 |
The 281839-6: This is the receptacle housing for the HE13/HE14 series, 12 positions in a dual-row layout on 0.100" (2.54mm) pitch.
The glass-filled PBT insulation material resists creep and maintains dimensional stability under heat and humidity.
No — the product note states contacts are not included.
0.100" (2.54mm) pitch, dual-row, with row spacing also 0.100" (2.54mm). This matches the standard HE13/HE14 header grid.
