Superseal 4-Position Plug Housing, 6.00 mm Pitch
The 282088-2: It is a free-hanging (in-line) connector with a latch-lock fastening system, designed for crimp-terminated female socket contacts. This is a housing only — contacts are not included and must be ordered separately.
What the 6.00 mm Pitch and Latch Lock Mean for Harness Assembly
The 6.00 mm pitch gives each contact position generous spacing, making the housing suitable for moderate-current power or signal circuits where creepage and clearance are a concern. The latch lock provides a positive mechanical retention when mated with the matching Superseal receptacle — it audibly clicks into place and resists vibration-induced disconnection, a common requirement in automotive and industrial environments.
Mating and Termination
This plug housing mates with the corresponding Superseal receptacle housing (same series, 6.00 mm pitch). Termination is via crimp contacts — the female socket contacts (not included) are crimped onto the wire and then inserted into the housing cavities. The latch lock secures the mated pair.
