TE Connectivity AMPMODU series, unshrouded breakaway header, 5 positions, single row, 2.00 mm pitch, through-hole right-angle, gold mating finish, 2 A, 125 VAC/DC, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Voltage rating | 125VAC/DC |
| Current rating | 2A |
| Operating temperature | -40°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The connector mates with any AMPMODU 2.00 mm pitch receptacle housing that accepts 5-position, single-row headers. The square male pins (0.64 mm typical for 2.00 mm pitch AMPMODU) engage with the receptacle's female contacts.
The mating pitch is 0.079" (2.00 mm). That is the centre-to-centre spacing between adjacent pins.
Yes, it is ROHS3 compliant.
