TE Connectivity AMP Connectors 2842150-7 — Pin Headers

2842150-7 TE Connectivity AMPMODU 14-Pin 2.00 mm

MPN2842150-7
Active

TE Connectivity AMPMODU series, 2842150-7: 14-position dual-row, 2.00 mm pitch, unshrouded breakaway header, right-angle through-hole, gold-plated mating pins, rated 2 A per contact at 125 VAC/DC.

$1.8500Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 2842150-7 datasheet (PDF)
RoHSROHS3 Compliant
SeriesAMPMODU
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

2842150-7 key specifications
ParameterValue
SeriesAMPMODU
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader, Breakaway
Fastening typePush-Pull
Voltage rating125VAC/DC
Current rating2A
Operating temperature-40°C~125°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.059\" (1.50mm)
Insulation materialThermoplastic

All specifications

2842150-7 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTube
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions14
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.110\" (2.79mm)
Contact finish - matingGold
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating3.94µin (0.100µm)

Product details

2 A per Contact with Gold Flash Mating Surface

The 2842150-7: The mating contact finish is gold at 3.94 µinch (0.100 µm) thickness over a copper alloy base. This is a flash-grade gold layer: it provides corrosion protection during storage and initial mating, but the mating cycle life is limited compared to thicker gold (15 µinch or more). In a low-cycle application (fewer than 50 matings) the flash gold is sufficient; for repeated field-service disconnect, a thicker-plated sibling in the AMPMODU range would be a better fit.

Right-Angle Through-Hole, UL94 V-0 Housing

Frequently asked questions

What connector mates with 2842150-7?

This is an unshrouded male pin header. It mates with any AMPMODU or compatible 2.00 mm pitch female receptacle housing that accepts 0.157-inch (4.00 mm) mating pin length. The push-pull retention means the mating half relies on friction fit — no locking latch.
