TE Connectivity AMPMODU series, 2842155-6, board-to-board header, 12 positions, 2.00 mm pitch, unshrouded, male pin, right-angle through-hole, gold mating finish, 2 A, 125 VAC/DC
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Voltage rating | 125VAC/DC |
| Current rating | 2A |
| Operating temperature | -40°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Tube |
| Features | Pick and Place |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 12 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 2842155-6: The breakaway design allows depopulating the header to a custom position count — the 12 positions are all loaded as shipped, but the snap-off grooves let a builder trim to a shorter array for a non-standard mating receptacle.
The part is ROHS3 compliant and supplied in tube packaging. No official replacement or successor part number has been issued.
The 2842155-6 is a 12-position header with a 2.00 mm mating pitch and 2.00 mm row spacing.
