TE Connectivity AMPMODU, 10-circuit dual-row unshrouded header, 2.00 mm pitch, gold-plated mating pins, right-angle through-hole, rated 2 A at 125 VAC/DC, -40°C to 125°C, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Voltage rating | 125VAC/DC |
| Current rating | 2A |
| Operating temperature | -40°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 10 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 2842163-5: Gold plating on the mating contact (15.0 µinch/0.38 µm) over a copper alloy base gives reliable low-resistance connections through repeated mating cycles — rated for at least 500 cycles in typical AMPMODU applications.
ROHS3 compliant, meeting the latest restriction of hazardous substances directive for lead-free and environmentally regulated markets.
Common mates include TE AMPMODU receptacles with the same pitch and row spacing.
