TE Connectivity AMPMODU series, 2842163-6, 12-position dual-row unshrouded breakaway header, 2.00 mm pitch, through-hole right-angle, gold-plated male pins, 2 A, 125 VAC/DC, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Voltage rating | 125VAC/DC |
| Current rating | 2A |
| Operating temperature | -40°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 12 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 2842163-6 offers 12 positions versus 4, a tighter 2.00 mm pitch, and gold plating — better suited for higher-density signal routing where the unshrouded profile fits the board-edge clearance. The 1-1871673-2's shrouded walls and lock add vibration resistance for cable-to-board duty, but the 2842163-6 covers more circuits in a smaller footprint for board-to-board stacks.
Yes, 2842163-6 is ROHS3 compliant.
As an unshrouded breakaway header, it mates with any AMPMODU 2.00 mm pitch receptacle that accepts a 0.157-inch (4.00 mm) mating pin length. The mating half is typically a female socket housing with crimp terminals from the same series — confirm the receptacle part number against the pin length and row spacing for a positive mate.
