TE Connectivity 284391-3 Buchanan Terminal Block, 3 Pos

MPN 284391-3
Active

TE Connectivity Buchanan 284391-3, 3-position PCB terminal block, 3.50mm pitch, 12 A, 300 V, side-entry rising cage clamp, green PA66 housing, through-hole, M3 screw.

$1.3300 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesBuchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

284391-3 key specifications
ParameterValue
SeriesBuchanan
MountingThrough Hole
Voltage300 V
Current12 A
Wire gauge14-30 AWG
Wire terminationScrew - Rising Cage Clamp
ColorGreen
Housing materialPolyamide (PA66), Nylon 6/6
Clamp material - platingBrass - Nickel Plated
Screw material - platingBrass - Nickel Plated
Contact material - platingBrass - Tin Plated
Pitch0.138\" (3.50mm)

All specifications

284391-3 additional specifications
ParameterValue
PackageBulk
FeaturesInterlocking (Side)
Screw threadM3
Torque - screw0.25 Nm (2.2 Lb-In)
Number of levels1
Mating orientationHorizontal with Board
Positions per level3

Product details

It uses a rising cage clamp termination — turning the M3 screw pulls a brass clamp plate up against the wire, creating a gas-tight connection that handles solid or stranded conductors from 14 AWG down to 30 AWG.

Interlocking Side Feature for Ganging

Each 284391-3 block has an interlocking (side) feature that lets you snap multiple blocks together side-by-side without extra brackets or end plates. This builds a multi-position strip at the same 3.50 mm pitch — useful when your BOM calls for more than three circuits but you want to keep a single continuous footprint on the PCB. The interlock is mechanical only; electrical continuity between blocks is handled by your PCB traces or jumpers.

Termination and Torque Specs

The rising cage clamp accepts stripped wire directly into the clamp opening. The M3 screw has a recommended torque of 0.25 Nm (2.2 Lb-In) — overtightening can strip the brass threads or deform the clamp plate. Both the screw and clamp are brass with nickel plating, which resists corrosion in industrial cabinet environments.
