7-Position 2mm Shrouded Header with Detent Lock
The 4-wall shroud and detent lock prevent mismating and hold the pair together under vibration — a common requirement for board-to-cable/wire applications.
292133-7 TE Connectivity AMP Connectors 7-Pin 2mm Header
MPN292133-7
Active
TE Connectivity AMP Connectors CT series, 292133-7, Board to Cable/Wire, Header, Male Pin, 7 Positions, 0.079" (2.00mm) Pitch, Through Hole, Shrouded - 4 Wall, Detent Lock, Tin Mating Finish, UL94 V-0
$0.5500Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesCT
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | CT |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 125VAC |
| Current rating | Varies by Wire Gauge |
| Contact material | Brass |
| Insulation color | Natural |
| Insulation height | 0.268\" (6.80mm) |
| Insulation material | Polyamide (PA66), Nylon 6/6 |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Circular |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 7 |
| Contact finish - post | Tin |
| Contact length - post | 0.126\" (3.20mm) |
| Overall contact length | 0.358\" (9.09mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.165\" (4.20mm) |
Product details
Frequently asked questions
Is 292133-7 a shrouded header with a detent lock?
Yes.
What is the closest alternative to 292133-7?
The peer MPN 1-292164-1 is the same CT series and style but in a right-angle orientation with 11 positions. If you need a straight 7-position header, 292133-7 is the direct fit.
