TE Connectivity AMP CT series, 292172-8, shrouded header, 8 circuits, 2.00 mm pitch, surface-mount, tin-plated contacts, detent lock, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | CT |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 125VAC |
| Current rating | Varies by Wire Gauge |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.307\" (7.80mm) |
| Insulation material | Polyamide (PA6T), Nylon 6T, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Tube |
| Shrouding | Shrouded - 3 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Circular |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 8 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.177\" (4.50mm) |
ROHS3 compliant per the current revision; no exemption expiry to track.
If the board layout calls for a right-angle exit and through-hole retention, the 1-292164-1 covers that fit; the 292172-8 serves SMT vertical-mount applications.
Yes, the 292172-8 is ROHS3 compliant per the current TE Connectivity revision.
